Seems FDMC is meaningful part

BQ25713
FDMC

FDMC

Seems FDMC is meaningful part

LT 018 3955
MAX77711C

PA6I
QTZ
QTZ
QTZ
QUJ

CYPD3126-4
OZ797SD2
PI6CG18
PI6CG18
PI6CG18
RTL8119I
Type1VY WiFi
VC125

CY9AF004

(LC-1051 LCD flex)

SHX7000 shutter

Sony A6000

Also known as:

Sony ILCE-6000

Any other parts or stuff

E-mount bayonet

Sony A6000 PCB SY-1028

Sony A6000 shutter button

Sony SD MS combo reader

OUJ

M02

(Sony A6000 flash flex)

ZE (TIG065E8)

12904

76312

KM4714030
Type WN WiFi

(ECX333A viewfinder)
(LC-1018 lcd flex)
AM30X548BA3 (4290 fl)

MB charge unit (2000, 2200)

Sony A6300

Also known as:

Sony ILCE-6300

Any other parts or stuff

E-mount bayonet

Sony A6000 shutter button

Sony A6300 PCB SY-1066

Sony SD MS combo reader

1K2

(Sony A6000 flash flex)

ZE (TIG065E8)

112B
263 8452

KM6N16118
Type WN WiFi

(ECX334A viewfinder)
(lc-1030 lcd flex)

AM30X548BA3 (4290 fl)

MB charge unit (2000, 2200)

Sony A6300 shutter AFE-3111

Внимание: затвор встречается как версии A6300 так и A6000, затворы не совместимы и отличаются шторкой у датчика

Sony A6400

Also known as:

Sony ILCE-6400

Any other parts or stuff

E-mount bayonet

Sony A6000 shutter button

Sony A6400 PCB SY-1094

Sony SD MS combo reader

CXD4236-2GG
CXD90045GG

1K2

SS6N04005
Type 1DR WiFi

(LC-1042 lcd flex)
6203B00234101 (GE0300SC00A1S)

Разные дисплеи, не совместимые между собой.

touch

MB charge unit (2000, 2200)

CXD4236-2GG
CXD90014GF STACKED

вместо защитного стекла на дисплее тачскрин, встречаются разные типы дисплеев!

Sony A6500

Also known as:

Sony ILCE-6500

Any other parts or stuff

E-mount bayonet

Sony A6000 shutter button

Sony A6500 PCB (SY-1077)

Sony SD MS combo reader

1K2

(Sony A6000 flash flex)

ZE (TIG065E8)

112B
263 8452

SS6N04005
Type 1DR WiFi

(ECX334A viewfinder)
(FP 390C-F0F viewfinder)
(lc-1030 lcd flex)

AM30X548BA3 (4290 fl)

touch

Sony A6500 shutter

вместо защитного стекла на дисплее тачскрин

Sony A7

Also known as:

Sony ILCE-A7

Any other parts or stuff

E-mount bayonet

FDA EP-12 Eyepiece

Sony A7 PCB (SY-1022)

Sony SD MS combo reader

SS3005071
Type WN WiFi

T08100EAA, T08155AAA (2751 fl)

(LC-1014 lcd flex)

Без защитного стекла

Sony AFE-3313 shutter

Предположительно он, стекло вклеено

Sony A7 (3)

Also known as:

Sony A7 III

Sony A7 mk III

Sony A7M3

Sony ILCE-A7M3

Any other parts or stuff

E-mount bayonet

FDA EP-12 Eyepiece

Sony A7 (3) PCB SY-1086

Sony SD MS combo reader

Backlight IC R1207N823B (403XX)

403XX sot23-6

4695
9950A

SS810609
Type 1DR WiFi
VC125

(ECX331D viewfinder)
(LC-1039-11 lcd flex)

NP-FZ100

1540350820

MB charge unit (5400)

Sony AFE-3360 shutter

AFE-3360 for A7M3, AFE-3313 for A7s

Sony A7 (4)

Also known as:

Sony A7 IV

Sony A7 mk IV

Sony A7M4

Sony ILCE-A7M4

Any other parts or stuff

E-mount bayonet

Sony A7 (4) PCB SY1122

(D9XFN RAM)
CXD90058GF STACKED

(D9VQG RAM)
CXD90057GF Stacked

AUM
AUM
BD8331

(LC-1048 lcd flex)
6203B00266100 (GE0300SC0051S)

BQ52713
BSG TI
ICS V0441AIL
Type 1DR WiFi
VC125

CY9AF004

NP-FZ100

MB charge unit (5600)

Sony AFE-3360 shutter

AFE-3360 for A7M3, AFE-3313 for A7s

Sony A7 (4A)

Also known as:

Sony A7 IVA

Sony A7 mk IVA

Sony A7M4A

Sony ILCE-A7M4A

Any other parts or stuff

Sony A7 (4A) PCB

CXD90058GF STACKED

AUM
AUM
BD8331

AFE-3360 for A7M3, AFE-3313 for A7s

BQ52713
BSG TI
ICS V0441AIL
Type 1DR WiFi
VC125

CY9AF004

NP-FZ100

MB charge unit (5600)

Sony AFE-3360 shutter

Sony A77M2

Also known as:

Sony ILCA-77M2

Any other parts or stuff

FDA EP-12 Eyepiece

Sony A77M2 PCB

Sony SD MS combo reader

BU79T272
HPL404
HPL404
KM4N25026
Type WN WiFi

TMP19A44FDAXBG
U7050GUW

NP-FM500H

(lcd-022-21 lcd flex)

Sony A77 mirror box

antishake = Sony A33

Совместимость шлейфа дисплея пока под вопросом

Sony A7c

Any other parts or stuff

Sony A7c PCB SY-1111

(D9WXP RAM)
CXD90045GG

CMOS Processor stacked

2G=4M
8072PN

USB power management

BD8331

BD8336
MPMH 3432
QTZ
QUJ

BU79T272
Type 1DR WiFi
VC125

1540350820

Sony A7R

Also known as:

Sony ILCE-A7R

Any other parts or stuff

E-mount bayonet

FDA EP-12 Eyepiece

Sony A7 PCB (SY-1022)

Sony SD MS combo reader

SS3005071
Type WN WiFi

T08100EAA, T08155AAA (2751 fl)

(LC-1014 lcd flex)

Без защитного стекла

Sony AFE-3313 shutter

Предположительно он, стекло вклеено

Sony A7R (2)

Also known as:

Sony A7R2

Sony A7RM2

Sony ICLE-7RM2

Any other parts or stuff

E-mount bayonet

FDA EP-12 Eyepiece

Sony A7R (2) PCB SY-1058

Sony SD MS combo reader

(H5TC4G63CFR)
CXD4236-1GG
CXD90014GF STACKED

CXD90027GF

1200 56F
54326
8072PN

USB power management

BD8331

Backlight IC R1207N823B (403XX)

403XX sot23-6

4695
9950A

BD11600N

USB switch

KM5911312
Type WN WiFi

(ECX331C viewfinder)
(FP500A viewfinder)
(LC-1027-11 lcd flex)

MB charge unit (5000)

Sony AFE-3379 shutter

AFE-3379 for A7S2

Кнопка спуска угольная

Sony A7R (3)

Also known as:

Sony A7R mark III

Sony A7RM3

Sony ICLE-7RM3

Any other parts or stuff

E-mount bayonet

FDA EP-12 Eyepiece

Sony A7R (3) PCB

Sony SD MS combo reader

CXD90045GG

2G=4M
BD8331

BD8336
OAP TI
QIZ
QUJ

TPS63061

R2J30503

112B
263 8452

TC358775XBG EVF controller

358775G

4695
787FJ2LN
8072PN
9950A

EY2657
SS0529009
Type 1DR WiFi

CXD4236-1GG
CXD90014GF STACKED

(ECX337A viewfinder)

(LC-1039-11 lcd flex)

LPM030M130C (A1075 flex)

MB charge unit (5400)

Sony AFE-3379 shutter

AFE-3379 for A7S2

Sony A7s (2)

Also known as:

Sony A7S2

Sony ILCE-7SM2

Any other parts or stuff

E-mount bayonet

FDA EP-12 Eyepiece

Sony A7s (2) PCB SY-1063

Sony SD MS combo reader

Backlight IC R1207N823B (403XX)

403XX sot23-6

(LC-1027-11 lcd flex)

MB charge unit (5000)

Sony AFE-3379 shutter

AFE-3379 for A7S2

Sony HX90

Any other parts or stuff

Micro USB cable

Sony HX90 PCB

T08100EAA, T08155AAA (2751 fl)

Без защитного стекла

Sony HX90

Sony NEX-5T

Any other parts or stuff

E-mount bayonet

Sony A6000 shutter button

Sony NEX-5T PCB

Sony SD MS combo reader

CXD90016GF
DSP STACKED

A30235
BD8330A

12904

76312

audio processor

D4909
HPY404
SS3807051

TMP19A44FDAXBG

(LC-1001 1-886-396-11 lcd flex)

1-886-319-11 (412AKR1)

=1-881-213-11 (412AKQ1), отличается стеклом

touch

CXD4236-2GG
CXD90014GF STACKED

Shutter: 1-487-619-21

Sony RX10 mark II

Also known as:

Sony DSC-RX10M2

Sony RX10M2

Any other parts or stuff

Sony RX10 mark II PCB

Sony SD MS combo reader

CXD90027GF

54326
63577
BD8331

4695
8072PN
9950A

B0L
FF1160
Type WN WiFi

(LC-1024-11 lcd flex)

CXD4236-2GG
CXD90014GF STACKED

Sony RX10 mark II

Sony RX10 mark III

Also known as:

Sony DSC-RX10M3

Any other parts or stuff

Sony RX10 mark III PCB

Sony SD MS combo reader

1KK

(ECX334A viewfinder)
(LC-1024-11 lcd flex)

Sony RX10 mark III

Sony RX100 II

Also known as:

Sony DSC-RX100M2

Any other parts or stuff

Sony RX100M2 PCB

Sony RX100m2 thumb rubber

Sony SD MS combo reader

B0A 337
D4908
Type WN WiFi

(LC-1009-21 lcd flex)

Sony RX100

Sony RX100 III

Also known as:

Sony RX100M3

Any other parts or stuff

Sony RX100 III PCB

Sony RX100m2 thumb rubber

BU79T272
KM8309060
Type WN WiFi

76381

(LC1021 lcd flex)
432BLQ1 (1-886-326-11)

Sony RX100 V

Sony RX100 V

Also known as:

Sony DSC-RX100M5

Sony RX100M5

Any other parts or stuff

Sony RX100 V PCB

Sony SD MS combo reader

CXD4236-1GG
CXD90014GF STACKED

44C031
6343V
OAP TI

8417 bga
AAV
R2J30503

112B
1464

7232
9950A

B0L
KM7418044
LVDS311
Type WN WiFi

76381

(fp-2350-11 viewfinder flex)
(LC1021 lcd flex)
432BLQ1 (1-886-326-11)

Sony RX100 V

Sony WX350

Also known as:

Sony DSC-W350

Any other parts or stuff

Sony SD MS combo reader

Sony WX350 PCB

76381
